Z shaped steel purlin cold roll forming machine

  • Z shaped steel purlin cold roll forming machine
  • Z shaped steel purlin cold roll forming machine
  • Z shaped steel purlin cold roll forming machine
  • Z shaped steel purlin cold roll forming machine

Z shaped steel purlin cold roll forming machine

    Payment Type: L/C,T/T,D/P,Western Union
    Terms of Trade: FOB
    Min. Order: 1 Set/Sets
    Delivery Time: 45 Days
    Packaging: nude packing
    Productivity:  8-15 m/min
    Brand: zhongtuo
    Transportation: Ocean,Land
    Place of Origin: China
    Supply Ability: 30 sets per month
    Certificate: CE ISO9001

Basic Info

Model No.: ZT-005-09

Product Description

Z shaped purlin cold roll forming machine Z steel purlin machine

Product Description

Machine Description: Z shaped purlin cold roll forming machine Z steel purlin machine

Quantity: 1 SET

Delivery time: 45 working days after receiving deposit

Container Type: One 40GP


Z Steel Purlin Machine Process Flow:

Uncoiling→Feeding material into machine→Roll forming→Measuring length→ Auto cutting→Products receiving

Product name: Z Shaped Making Machine

1.SuitableMaterial

Type: GI/PPGI/AL

Thickness: 2.0-3.0mm

2. ProductmSpecifications

Length: Any length

Length Tolerance: ±2mm/6m

3. Working Speed: 8-15 m/min (Standard machine)

4. Control System: Mitsubishi/Siemens PLC& transducer (Custom)

5. Total Power: 6KW

6. Total Weight: About 6.2T (Up to final design)

Un-coiler System

Detailed information of Z shaped purlin cold roll forming machine

Usage: It is used to support the steel coil and uncoil it in a turntable way. Passive uncoil pulled by roll forming system

Coil feeding part

Usage: Put the raw material(steel plate) through the beach to manufacture and process,it can guarantee that the products are neat, parallel and everything is uniformity.Please refer to the equipment regulation to know the function of locate angle iron.

DSC04844

Forming device

Usage: In order to keep the product shape and precision, adopts welded sheet structure, motor reducer drive, chain transmission,roller was chromed which can keep the molding plate surface smooth and not easy to be marked when it is working

Feature : Ensure stability , precision and lifetime.

Z shaped purlin cold roll forming machine


Main parameter of Z Steel Purlin Machine

1.Length of the main part: 6800*800*1200mm

2. Weight of main part: About 6.2 t

3. Voltage: 380V/50HZ3Phase (as customer`s request)

4.Roller fixer: Guide column

5. Frame: Middle plate welded: Memorial arch frame type

6. Frame thickness: 25mm

7.Drive mode: Gear or chain

8. Material of rollers: 45# steel with tempering

9. Material of shafts: 45# steel with tempering

10. Diameter of shafts: φ80mm

11. Number of rollers: 12rollers

14. Main power:11kw (Cycloidal planetary gear speed reducer)

Cutting device

Advanced hydraulic drive flying saw cutting, automatic punching and cutting after forming, no distorting or wasting, high level safety factor. Flying saw punching Z steel equipment is a kind of Z steel machine cut, it adapt after cut. This cut off the way do not need to change model,You can added the punch in the flying saw device at the same time to achieve the effect of flying saw punching if you need.

Blade Material: Cr12 steel with quenched treated 60-62°C

Cutting system: Full automatic


cutting

Punching device

Features: punching is a part of the the flying saw cutting, is controlled by hydraulic station, mainly punches holes at Z steel , Whether puching is according to pople's need, easy to control use conveniently and long life.

Power: 3kw(double values)

material: Cr12

quantity: 2

oil cylinder: 2

Controlling device

Screen: Text screen displayer

PLC: Taida DVP14ES from Taiwan

Coder: Omron

Hydraulic

Orgin: Advanced hydraulic system from Taiwan

Power: 3kw
